| Model No | SE0813-3 | |
| Image Format Cover | 2/3" ～ 1/3" | |
| 焦点距离 | 8.0 mm | |
| MAX光圈比率 | 1 : 1.3 | |
| Iris光圈 | 操作 | 手动调节 |
| Iris Range | F1.3 ～ Close | |
| FocusOperation | Focus 焦点 | 手调 |
| Scale | ||
| 视角 (D×H×V) |
1/3 inch | 40.0° × 32.4° × 24.6° |
| 1/2 inch | 51.7° × 42.4° × 32.4° | |
| 2/3 inch | 71.6° × 58.8° × 44.9° | |
| 1 inch | ||
| Minimum Object DistanceMIN可视距离 | 0.2 m | |
| Back Focal Length 后焦长度 | 11.58 mm | |
| Effective Diameter | Front 前部 | φ14.0 mm |
| Rear 后部 | φ11.4 mm | |
| Filter Screw size | M34.0 P=0.5 | |
| Mount | C / 17.526mm | |
| Mechanical Dimension(D×L)机械尺寸 | φ37.0mm × 30.0mm | |
| Weight重量 | 72.5g | |
| 应用温度环境 | -10°C ～ +50°C (+14°F ～ +122°F) | |
SE0813-3
